5.0 Surround Set

Beam

• Four full-range woofers ensure you’ll hear the faithful playback of mid-range vocal frequencies plus deep, rich bass.
• One tweeter creates a crisp and clear dialogue.
• Three passive radiators help move air around inside the compact Sonos Beam and add warm sound to the bass.
• Adjustable bass and treble controls let you customise your sound by individual room or groups of rooms.
• Five Class-D digital amplifiers perfectly tuned to match the speaker drivers and acoustic architecture.
• Five far-field microphone array used for advanced beamforming and multi-channel echo cancellation.
• When the microphone LED is on, Beam is ready for a voice command. When the light is off, the microphone is off.
• Dimensions - H x W x D

68.5 x 651 x 100 mm (2.70 x 25.625 x 3.94 in.)

• Weight

2.8 kg (6.2 lbs)

• HDMI ARC

HDMI Cable connects to your TV’s HDMI ARC input.

• Optical Audio

Optical Audio Adapter to connect to your TV.

• Top-panel features

Capacitive touch controls for volume up/down, previous/next track, play/pause, microphone mute. LED indicates status, mute status and voice feedback.

• Threaded mount

12.7 mm (1/2 in.) / 10-32 threaded mounting socket.


One SL

• Two Class-D digital amplifiers perfectly tuned to match the speaker drivers and acoustic architecture.
• One tweeter creates a crisp and clear high-frequency response.
• One mid-woofer ensures you’ll hear the faithful playback of mid-range vocal frequencies plus deep, rich bass.
• Adjustable bass and treble controls let you customise your sound by individual room or groups of rooms.
• Dimensions - H x W x D

161.45 x 119.7 x 119.7 mm (6.36 x 4.69 x 4.69 in.)

• Product finish

White with matte white grille; black with matte black grille.

• Top-panel features

Capacitive touch controls for volume up/down, previous/next track, play/pause. LED status light.

• Weight

1.85 kg (4.08 lbs.)


Power & Networking

• Power supply

Auto-switching 100-240 V, 50-60 Hz AC universal input.

• Ethernet port

One 10/100 Mbps Ethernet port. Wire directly to your router to operate your Sonos if WiFi is unstable, or use the Ethernet port to provide internet accessibility to non-wireless devices if you’re using Boost setup.

• WiFi, not Bluetooth

Connects to your home WiFi network with any 2.4GHz 802.11 b/g/n broadcast-capable router for uninterrupted wireless streaming. 5GHz is not supported—you can either enable 2.4GHz 802.11b/g/n in router settings or connect a Sonos product to your router.

• Apple AirPlay 2

Works with AirPlay 2 on Apple devices iOS 11.4 and higher.


Contents

• Sonos Beam, power cord, HDMI cable, Optical Audio Adapter, Quickstart Guide, and Legal Booklet
• 2 each of Sonos One SL, Power Cable, Quickstart Guide, and Legal Booklet
