CI Pro P65-IW

Rectangular, SHOCK-MOUNT™ Isolation Mounting System, In-Wall 2-way 6-1/2" Sensitivity 91.5 dB, 15...

Read More

$479.00
In Stock

Description

Rectangular, SHOCK-MOUNT™ Isolation Mounting System, In-Wall 2-way 6-1/2" Sensitivity 91.5 dB, 15 - 120 watts. Mounting depth 8.6cm

SPECIFICATIONS
DESIGN 2-driver, 2-way in-wall, SHOCK-MOUNT™ Isolation Mounting System, die-cast aluminum baffle
FREQUENCY RESPONSE ON-AXIS ±3 dB from 70 Hz - 22 kHz
HIGH FREQUENCY DRIVER 1" (2.5cm) X-PAL™ dome, ferro-fluid damped / cooled, Reduced Edge Diffraction (RED™) Technology, Perforated Phase-Aligning (PPA™) Tweeter Lens
MID/BASS FREQUENCY DRIVER 6.5" (16.5cm) mineral-filled polypropylene cone, overmolded Active Ridge Technology (ART™) surround, die-cast aluminum chassis
SENSITIVITY ROOM / ANECHOIC 91.5 dB / 87.5 dB
IMPEDANCE Compatible with 8 ohms
FINISHES White, paintable grille, black/grey speaker
WEIGHT 8.2 lbs. (3.7 kg)
LOW FREQUENCY EXTENSION 35 Hz
CROSSOVER 2nd-order electro-acoustic at 2.5 kHz
FREQUENCY RESPONSE 30° OFF-AXIS ±3 dB from 70 Hz - 18 kHz
SUITABLE AMPLIFIER POWER RANGE 15-120 W
MAXIMUM INPUT POWER 90 W
OVERALL DIMENSIONS 11.3125" (28.7cm) Height 8.125" (20.6cm) Width 3.875" (9.8cm) Depth
CUT-OUT DIMENSIONS 10.1875" (25.9cm) Height 7" (17.8cm) Width
MINIMUM MOUNTING DEPTH
(DEPTH REQUIRED IS THE DISTANCE BETWEEN 1/2" DRYWALL, OR SIMILAR MATERIAL.)
3.375" (8.6cm)
